Description

📌 General Info

• Brand: Itel

• Model: IPW-25100 (24 V 100 Ah LiFePO₄ battery)

• Type: LiFePO₄ (Lithium Iron Phosphate) — safe, stable, long-lasting chemistry.

⚡ Electrical & Energy Specs

• Nominal Voltage: ~25.6 V (24 V system)

• Rated Capacity: 100 Ah

• Energy Capacity: ~2.56 kWh (~2560 Wh)

• Nominal Operating Voltage Range: ~20 V – 28.8 V

⚡ Charge/Discharge Performance

• Standard Charge/Discharge Current: ~50 A

• Max Continuous Discharge: ~90–100 A

• Max Pulse (Short Burst) Discharge: ~120 – 150 A

• Recommended Charge Voltage: ~28.8 V

• Discharge Cut-off Voltage: ~20 V

🧠 Battery Life & Protection

• Cycle Life: >6,000 cycles @ 80 % Depth of Discharge — long service life (~10 + years).

• Battery Management System (BMS): Built-in smart BMS protecting against

  • Over-charge

  • Over-discharge

  • Short-circuit

  • Over-current

  • Temperature extremes

• Charge/Discharge Efficiency: >95 % (very efficient energy use)

📦 Physical & Installation

• Mounting: Wall-mount or floor/rack-mount options.

• Weight: ~27 – 30 kg (varies by supplier)

• Communication Ports: RS485 / CAN / RS232 available (for inverter/battery monitoring)

• Parallel Support: Can connect multiple units in parallel for larger storage (e.g., up to ~15 units)

🌡 Operating Conditions

• Discharge Temperature: ~-20 °C to +60 °C

• Charge Temperature: ~0 °C to +55 °C

• Storage Temperature: ~-10 °C to +45 °C

🔌 Usage & Compatibility

✔ Designed for 24 V hybrid/off-grid solar inverters (e.g., 3 kW, 3.6 kW or 4 kW Itel hybrid inverter)
✔ Suitable for home backup power, small businesses, offices, telecom, RV/boat systems
✔ Works well with MPPT solar charge controllers and hybrid inverter battery inputs.
